Panel indicators (DISCONTINUED)

Dri3M240A railway panel indicator (DISCONTINUED)

Informatie

Triple indicator for railway applications

Specificaties

General Specifications

Availibility
Available with 90o pointer deflection as Dri3M240A, or with 240o pointer defelction as D3riM240S.

Sizes
Front 240 x 96 mm
Panel cut out 236 x 92 mm

Illumincation supply
24 VAC/DC, other voltage on request

Approx. consumption
2 W

Illumination type
LED

Input
4...20 mA, 0...20 mA, +/- 20 mA, +/- 10 V, 0...V other inputs on request

Accuracy
+ 1.5 % of full scale

Scale background
Black

Pointer and text
Yellow or white

Illumination
Green, red or yellow

Pointer illumination
Red or yellow
Other colours are on requesst

Operating temperature
-25 °C...+70 °C

Humidity
at 40 °C, max 95 %
